• Trouble-free continuous operation :Closes bags at ease on the bagging line or in the field.
• Quiet operation :High-grade, wear-resistant nylon cam ensures minimum noise level in comparison to loud noise experienced in machines with steel cams during operation.
• Safety handle :Strong plastic handle for insulation.
• Non-corrosive finish :Essential as it helps resist corrosion in damp and humid conditions.
• Superior powerful lubricator : Lubrication system consists of an oil pump and a reservoir. Oil lines from the pump direct the lubricant to the main moving parts.
• Sealed Motor : Ideal as it provides the motor with a total dust-proof enclosure.
• Automatic thread cutter :Protected cutting blades sever the thread after the bag is closed.
• Timing Belt :15mm toothed belt helps the machine operate without much effort under tense workload.
• Adaptable :Stationary or suspended use can be attained from this machine without loss of useful portable features.
• Presser foot lifter and thread cone cover : Standard in all bag closing models.
• Optional accessories : Conveyor stands, shoulder belts, spring balancers with hangers are available at extra cos

SPECIFICATIONS

SEWING SPEED : Efficient production: Maximum sewing speed 1600-1800 stitches per minute

DIMENSIONS  : 12in. H x 12in. W x 13in. D (30 cm x 30 cm x 33 cm)

STITCH LENGTH  : 3.5 stitches/inch (25.4mm) Fixed

MAXIMUM MATERIAL THICKNESS  : 10mm

CUTTER TYPE  :  Mechanical

THREAD  : 8oz. Cotton or Synthetic thread cones.

NEEDLE SIZE  : DB X 1 200/25 Groz-Beckert

POWER REQUIREMENTS  : 220V

WEIGHT  : 6 kg.

TYPE OF STITCH : Single thread/chain stitch

CLOSING-SPEED  : 5 - 8 sec/bag, 39 fpm at 3.5 stitches/inch (25.4mm)

TYPES OF BAGS  : All kinds of multi-wall paper, kraft-paper, burlap, cotton, PP/PE, Hessian, woven polyester, jute bags etc

LUBRICANT  : For extended lubrication and wear, use SAE 30 Oil
